Following on from some customer feedback, we have found that not many people know that we offer a heavy-duty L-bracket for Spex back support shells.
WHO: For users over 136kg or who have extreme body movements.
WHY: These must be prescribed for any users with above conditions otherwise the standard L-brackets may potentially break.
HOW: Use order code 1259-2405-100 for Upgrade to Heavy Duty Quad Mount Hardware.
| Back Support size | 10″ to 15″ | 16″ to 20″ | 20″ + |
|---|---|---|---|
| Standard Weight Limit | 90 kg (200 lb) |
136 kg (300 lb) |
N/A (Must use Heavy-Duty) |
| With Heavy-Duty Quad Mount L-Brackets | 136 kg (300 lb) |
180 kg (400 lb) |
180 kg (400 lb) |
If you are installing a wider backrest on a narrower chair (i.e. an 18 inch backrest on a 16 inch chair), use these brackets as you need to mount through the holes as you can’t use the slots.
